General

• Type:

  Point source

• Transducers:

  0.5" neodymium magnet woofer

• Frequency Response:

  500 Hz – 18 kHz (-6 dB)

   ⁽¹⁾

• Max SPL:

  86 dB (peak)

   ⁽²⁾

• Rated Power:

  3.5 W

• Coverage:

  V. 140° | H. 140°

• Connectors:

  IN+ IN- screw terminals

• Nominal Impedance:

  16 Ω

Handling and Finishes

• Dimensions (W x H x D):

  22 x 37 x 11 mm (0.9 x 1.5 x 0.4 in)

• Weight:

  0.021 kg (0.046 lb)

• Material:

  Aluminum

• Colors:

  Black, White, Custom RAL

• Finishes:

  24K Gold, Polished

Regulations

• IP Rating:

  IP64

• (1) With dedicated preset.
• (2) Maximum SPL is calculated using a signal with crest factor 4 (12dB) measured at 1 m

• Passive loudspeakers requires dedicated preset loaded on board of K-array amplifiers.

• New materials and design are introduced into existing products without previous notice.

General

• Type:

  Passive subwoofer

• Transducers:

  4" woofer + passive radiator

• Frequency Response:

  45 Hz - 150 / 500 Hz (-6 dB)


   ⁽¹⁾

• Max SPL:

  112 dB (peak)

   ⁽²⁾

• Rated Power:

  60 W

• Coverage:

  Omni

• Connectors:

  2PIN euroblock connector (included)

• Nominal Impedance:

  4 Ω

Handling and Finishes

• Dimensions (W x H x D):

  122 x 117 x 199 mm (4.8 x 4.6 x 7.8 in)

• Weight:

  1.5 kg (3.31 lb)

• Material:

  Aluminum

• Colors:

  Black

• Finishes:

  Powder Matte

Regulations

• IP Rating:

  IP64

• (1) With dedicated preset
• (2) Maximum SPL is calculated using a signal with crest factor 4 (12dB) measured at 1 m.

• Passive loudspeakers requires dedicated preset loaded on board of K-array amplifiers.

• New materials and design are introduced into existing products without previous notice.

General

• Type:

  4ch switching mode, Class D Amplifier

• Output Power:

  4x 50 W @ 4 Ω

• Impedance:

  minimum 4 Ω (2 Ω PBTL)

• Frequency Response:

  20 Hz – 20 kHz (±1 dB)

• Connectors:

  Input:
  4x BAL input: Euroblock 1.5/ 3-ST-3.81,
  3.5 mm jack unBAL analog stereo AUX input,
  TOSLINK optical input,

  Output:
  2x Euroblock 2,5/ 4-G-5,08

  Digital:
  4x USB-A 2.0,
  1x RJ45 Ethernet,
  Bluetooth 4.1 Low Energy,
  Wi-Fi IEEE 802.11 b/g/n

• Built-in DSP:

  Grouping, Input EQ, Output EQ, Signal Routing, Level adjustment, Dynamic Limiters, Delay

• Remote Control:

  Wi-Fi dedicated K-array Connect mobile app. Ethernet wired K-framework3 multiplatform design and tuning software

• MAIN Operating Range:

  Dedicated AC/DC power adapter 100-240V ~ AC, 50-60 Hz input / 24 V, 4 A DC output

• Power Consumption:

  20 W @ 4 Ω load, Pink noise, 1/8 rated power

• Protections:

  Over Temp. (Power Limiting – Thermal Shutdown), Short Circuit/Overload Output Protection, Power Limiting, Clip Limiter/Permanent Signal Limiter, High Frequency Protection

Handling and Finishes

• IP Rating:

  IP20

• Dimensions (W x H x D):

  219 x 45,5 x 170 mm (8.6 x 1.8 x 6.7 in)

• Weight:

  0.7 kg (1.5 lb)

• Material:

  Aluminum
